The Schneider Electric Elau MAX-4/11/03/016/08/0/1/00 is a PAC-DRIVE servo controller designed for high-performance motion control applications. This unit is part of the Elau MAX-4 series, known for its robust integration capabilities within complex automation systems. Its specific configuration suggests suitability for demanding drive applications requiring precise control and communication.

Technical details

• Series: Elau MAX-4 PAC-DRIVE
• Model Configuration: MAX-4/11/03/016/08/0/1/00
• Voltage Class: The "11" in the part number typically indicates a 110-120V AC input voltage class for auxiliary power, while the main drive voltage class would need to be confirmed via datasheet.
• Current Rating: The "016" in the part number likely denotes a peak current rating of 16 Amps.
• Encoder Feedback: The "08" suggests an 8-bit encoder resolution or a specific encoder interface type.
• Communication Interface: The "0/1/00" segment of the part number often relates to communication options; further verification against the datasheet is recommended for specific protocols.
• Integrated Safety Functions: The presence of specific codes may indicate integrated safety features, which should be confirmed with manufacturer documentation.
• Axis Control: This unit is designed for single-axis control within the PAC-DRIVE architecture.

Applications & compatibility

This Elau PAC-DRIVE controller is commonly deployed in sophisticated automation environments such as high-speed packaging machinery, CNC machining centers, and complex material handling systems. Its robust design and precise control capabilities make it ideal for applications demanding accurate positioning and dynamic response.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the 13130251-006 or contact our technical team for cross-reference assistance with compatible Elau MAX-4 components.
