Schneider Electric's 20548 is a 2-pole circuit breaker designed for DC power distribution and protection. This unit is part of the Schneider Electric C-curve series, known for its reliable tripping characteristics in overload and short-circuit scenarios. It is engineered for applications requiring robust DC circuit interruption, commonly found in renewable energy systems, industrial DC power supplies, and specialized control panels.

Technical details

• Series: C-Curve
• Poles: 2
• Current Rating: 25 Amps
• Voltage Rating: 250 VDC
• Interrupting Capacity: 10 kA
• Mounting Type: DIN Rail Mount
• Tripping Curve: C-Curve (designed for moderate inrush currents)

Applications & compatibility

This Schneider Electric circuit breaker is suitable for use in DC power distribution systems within industrial automation, renewable energy installations such as solar inverters, and battery storage systems. Its C-curve characteristic makes it compatible with equipment that may experience temporary, moderate inrush currents during startup, such as motors or transformers, without causing nuisance tripping.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the 20548 or contact our technical team for cross-reference assistance with compatible Schneider Electric DC protection components.
