The Schneider Electric MasterPact NW series circuit breaker is designed for robust power distribution and protection in demanding industrial environments. This drawout type breaker, part of the MasterPact NW family, features front connections and is configured for top mounting. It is engineered to handle significant electrical loads, making it suitable for main incomer or feeder applications within large facilities.

Technical details

• Series: MasterPact NW
• Configuration: 3 poles
• Mounting Type: Drawout
• Connection Type: Front connection
• Mounting Orientation: Top mounting
• Rated Current: 2500A / 3200A (verify specific model configuration)
• Interrupting Capacity: Not specified in provided information; consult manufacturer datasheet for details.
• Voltage Rating: Not specified in provided information; consult manufacturer datasheet for details.

Applications & compatibility

This MasterPact NW circuit breaker is commonly deployed in medium-voltage distribution systems for large commercial buildings, data centers, manufacturing plants, and utility substations. Its drawout design facilitates safe maintenance and replacement, ensuring minimal downtime in critical power infrastructure. It is compatible with Schneider Electric's MasterPact NW switchgear systems.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric 48416 or contact our technical team for cross-reference assistance with compatible MasterPact NW components.
