The Schneider Electric 9012-ACW-9 is an electromechanical pressure switch designed for monitoring and controlling fluid pressure levels within industrial automation circuits. This switch is part of the 9012 series, a robust line of pressure control devices engineered for demanding environments. It is suitable for applications involving compressed air, oil, water, and non-corrosive gases, providing reliable operational feedback for system management.

Technical details

• Series: 9012
• Actuation Type: Electromechanical
• Fluid Compatibility: Compressed air, oil, water, non-corrosive gases
• Function: Pressure monitoring and control
• Switching Action: Typically configured as SPDT (Single Pole Double Throw) or SPST (Single Pole Single Throw) depending on internal configuration; consult datasheet for specific internal contact arrangement.
• Electrical Rating: Voltage and amperage ratings vary based on specific configuration and application; refer to manufacturer datasheet for precise electrical specifications.
• Operating Temperature Range: Consult manufacturer datasheet for specific environmental operating limits.
• Enclosure Type: Designed for industrial environments; specific NEMA or IP rating should be verified via manufacturer documentation.

Applications & compatibility

This pressure switch is commonly integrated into pneumatic control systems, hydraulic circuits, and general industrial machinery. Applications include, but are not limited to, compressor control, pump operation management, and process line pressure regulation in sectors such as manufacturing, food and beverage processing, and material handling.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the 9012-ACW-9 or contact our technical team for cross-reference assistance with compatible Schneider Electric pressure control components.
