The Schneider Electric C60PV-DC is a 2-pole miniature circuit breaker designed for DC power distribution applications. This specific unit, identified by the part number A9N61650, operates within the B curve tripping characteristic, indicating a specific overload and short-circuit protection response suitable for certain DC circuits. It is engineered to provide reliable circuit protection in systems requiring a robust and dependable DC switching device.

Technical details

• Series: C60PV-DC
• Poles: 2
• Current Rating: 10 A
• Voltage Rating: 800 VDC
• Trip Curve: B Curve
• Application: DC circuit protection
• Construction: Miniature circuit breaker
• Manufacturer: Schneider Electric

Applications & compatibility

This Schneider Electric circuit breaker is commonly utilized in photovoltaic (PV) systems for DC string protection, as well as in other DC power distribution networks where 800 VDC protection is required. Its B curve characteristic makes it suitable for protecting circuits with low inrush currents, such as those found in solar installations and certain industrial DC power supplies.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the A9N61650 or contact our technical team for cross-reference assistance with compatible C60PV-DC components.
