The Schneider Electric C60PV-DC is a 2-pole circuit breaker designed for DC power distribution applications. This unit operates within the B curve tripping characteristic, indicating a specific response to overcurrent conditions suitable for protecting DC circuits. It is commonly integrated into solar photovoltaic (PV) systems and other DC power management setups requiring reliable overcurrent protection.

Technical details

• Series: C60PV-DC
• Poles: 2
• Current Rating: 25 A
• Voltage Rating: 800 VDC
• Tripping Curve: B curve
• Application: DC circuit protection
• Type: Miniature Circuit Breaker (MCB)

Applications & compatibility

This Schneider Electric circuit breaker is specifically engineered for DC applications, making it suitable for use in solar power installations, battery storage systems, and DC motor control circuits. Its 800VDC rating and 25A capacity allow for integration into medium-power DC distribution panels and equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the A9N61660 or contact our technical team for cross-reference assistance with compatible DC protection components.
