The AMETEK Gemco Electric 953A-V7-1560-X-X-M-X-C is a 953A VMAX™ LDT analog version. It belongs to AMETEK Gemco Electric's Vmax™ series of linear displacement transducers (LDTs), used to provide continuous electronic position feedback on cylinders and other linear-travel machine elements.

The Vmax™ series extends Gemco Electric's linear displacement transducer catalog with a design built around the company's available output and stroke-length options in a Vmax™-specific housing. As with the rest of the Gemco LDT range, sensing is non-contact, which helps the transducer maintain accuracy through repeated extension and retraction cycles. AMETEK supports parts such as the 953A-V7-1560-X-X-M-X-C as part of a broader catalog of industrial instrumentation and electromechanical components, sourced to match the original fit, form, and function of the unit being replaced.

Key Features and Specifications:

• 5 to -5 VDC output
• 156 inch stroke length
• 2 inch null zone
• 2.5 inch dead band
• 6 pin DIN MTS
• Style D60 no option

For maintenance and retrofit projects, the 953A-V7-1560-X-X-M-X-C is typically ordered using its full configured part number to guarantee compatibility with existing wiring and mounting, since Gemco's Vmax™ LDTs are built to a specific combination of stroke and output parameters.
