The Schneider Electric ComPacT NSX100F is a 1-pole circuit breaker designed for AC/DC applications. This unit features a 40A trip unit and a breaking capacity of 18kA at 240VAC, making it suitable for protecting electrical circuits in demanding industrial environments. It is part of the ComPacT NSX series, known for its robust construction and reliable performance in power distribution systems.

Technical details

• Series: ComPacT NSX
• Model: NSX100F
• Poles: 1
• Rated Current (Trip Unit): 40A
• Breaking Capacity: 18kA at 240VAC
• Voltage Compatibility: AC/DC
• Trip Unit Type: TMD (Thermal Magnetic Differential)
• Enclosure Type: Molded Case Circuit Breaker (MCCB)

Applications & compatibility

This circuit breaker is commonly employed in motor control centers, power distribution panels, and machinery control systems across various industries. Its specifications make it compatible with applications requiring protection for circuits up to 40A with a moderate breaking capacity, such as those found in conveyor systems, pump controls, and HVAC equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the C10F1TM040 or contact our technical team for cross-reference assistance with compatible ComPacT NSX components.
