The Schneider Electric ComPacT NSX100F circuit breaker is engineered for robust AC/DC power distribution and protection. This 2-pole breaker, part of the ComPacT NSX series, features a 40A TMD trip unit and a breaking capacity of 18kA at 415VAC, making it suitable for demanding industrial environments.

Technical details

• Series: ComPacT NSX
• Model: NSX100F
• Poles: 2
• AC/DC Rated Current: 40A (TMD trip unit)
• Breaking Capacity: 18kA at 415VAC
• Trip Unit Type: TMD (Thermal Magnetic Differential)
• Voltage Rating: Suitable for 415VAC systems
• Application: AC/DC circuit protection

Applications & compatibility

This circuit breaker is designed for use in industrial electrical distribution systems, including motor control centers, power distribution panels, and machinery control cabinets. It provides reliable protection for circuits in applications such as manufacturing lines, material handling systems, and process control equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the C10F2TM040 or contact our technical team for cross-reference assistance with compatible ComPacT NSX components.
