The Schneider Electric ComPacT NSX100F circuit breaker is designed for AC and DC power distribution and protection applications. This 2-pole breaker is part of the ComPacT NSX series, known for its robust performance in demanding industrial environments. It features a TMD trip unit rated for 100A and a breaking capacity of 18kA at 415VAC.

Technical details

• Series: ComPacT NSX
• Model: NSX100F
• Poles: 2
• AC/DC Compatibility: Suitable for both AC and DC circuits.
• Breaking Capacity: 18kA at 415VAC.
• Trip Unit Type: TMD (Thermal Magnetic Differential)
• Current Rating: 100A
• Voltage Rating: 415VAC (for breaking capacity specification). For other voltage ratings, please consult the manufacturer's datasheet.

Applications & compatibility

This circuit breaker is commonly employed in electrical distribution panels, motor control centers, and power management systems across various industries. Its versatility makes it suitable for protecting circuits in manufacturing plants, data centers, and infrastructure projects where reliable power interruption is critical.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the C10F2TM100 or contact our technical team for cross-reference assistance with compatible ComPacT NSX components.
