The Schneider Electric ComPacT NSX100F circuit breaker is engineered for robust electrical protection in industrial environments. This 3-pole unit features a 36kA interrupting capacity at 415VAC and incorporates an MA trip unit rated for 50A. It is designed to safeguard electrical circuits from overcurrents and short circuits, ensuring operational continuity and equipment safety in demanding applications.

Technical details

• Series: ComPacT NSX
• Model Designation: NSX100F
• Number of Poles: 3
• Rated Breaking Capacity: 36kA at 415VAC
• Trip Unit Type: MA (Magnetic-Thermal)
• Current Rating: 50A
• Voltage Rating: 415VAC
• Frame Size: 100A

Applications & compatibility

This circuit breaker is suitable for use in motor control centers, power distribution panels, and machine control systems across various industries. It is commonly found in applications requiring reliable protection for circuits feeding motors, transformers, and other inductive loads, such as on packaging lines, material handling equipment, and manufacturing machinery.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the C10F3MA050 or contact our technical team for cross-reference assistance with compatible ComPacT NSX components.
