The Schneider Electric ComPacT NSX100F is a molded case circuit breaker designed for robust electrical protection in industrial environments. This 4-pole unit features a TMD trip unit and is rated for 16A at 50 degrees Celsius, providing reliable circuit interruption for systems requiring a 36kA breaking capacity at 415VAC. It is commonly integrated into power distribution panels and motor control centers.

Technical details

• Series: ComPacT NSX100F
• Number of Poles: 4
• Rated Current: 16A
• Trip Unit Type: TMD
• Breaking Capacity: 36kA at 415VAC
• Operating Temperature: 50 degrees Celsius
• Enclosure Type: Molded Case
• Terminal Type: Screw terminals (verify specific configuration against datasheet)

Applications & compatibility

This circuit breaker is suitable for use in a wide range of industrial applications including motor control circuits, power distribution for machinery, and protection of electrical feeders in manufacturing plants. It is compatible with systems requiring reliable overcurrent and short-circuit protection up to its rated breaking capacity.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric C10F4TM016C or contact our technical team for cross-reference assistance with compatible ComPacT NSX components.
