The Schneider Electric ComPacT NSX100H is a 3-pole circuit breaker designed for robust electrical protection in industrial environments. This unit features a TMD trip unit rated for 16A and offers a significant breaking capacity of 70kA at 415VAC. It is commonly integrated into power distribution systems and motor control circuits where reliable fault interruption is paramount.

Technical details

• Series: ComPacT NSX
• Model Designation: NSX100H
• Number of Poles: 3
• Rated Current (Trip Unit): 16A
• Breaking Capacity: 70kA at 415VAC
• Trip Unit Type: TMD (Thermal Magnetic Drawout)
• Voltage Rating: 415VAC
• Enclosure Type: Drawout (indicated by 'H' in part number, typically for drawout versions)

Applications & compatibility

This circuit breaker is suitable for use in a wide range of industrial applications including motor control centers, power distribution panels, and machinery requiring precise overcurrent and short-circuit protection. Its high breaking capacity makes it ideal for systems with significant fault current potential, such as those found in manufacturing plants, data centers, and utility substations.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the C10H3TM016 or contact our technical team for cross-reference assistance with compatible ComPacT NSX components.
