The Schneider Electric ComPacT NSX100N circuit breaker is engineered for robust AC and DC power distribution and protection. This 1-pole unit features a TMD trip unit with an 80A rating, designed to safeguard electrical circuits in demanding industrial environments. Its construction supports a breaking capacity of 25 kA at 240 VAC, making it suitable for applications requiring reliable fault interruption.

Technical details

• Series: ComPacT NSX100N
• Type: Molded Case Circuit Breaker
• Poles: 1
• Trip Unit Type: TMD
• Current Rating: 80 A
• Breaking Capacity: 25 kA at 240 VAC
• Voltage Compatibility: AC/DC
• Configuration: 1d (refer to manufacturer datasheet for specific configuration details)

Applications & compatibility

This circuit breaker is commonly deployed in motor control centers, power distribution panels, and control cabinets for various industrial machinery. It is compatible with systems requiring precise overcurrent and short-circuit protection, including conveyor systems, pump controls, and HVAC units.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the C10N1TM080 or contact our technical team for cross-reference assistance with compatible ComPacT NSX components.
