The Schneider Electric ComPacT NSX100HB1 is a 3-pole circuit breaker designed for robust electrical protection in industrial environments. Featuring a 75kA interrupting capacity at 690VAC, this unit is engineered to safely manage fault currents in demanding applications. It incorporates the MicroLogic 6.2EM trip unit, providing advanced monitoring and control capabilities.

Technical details

• Series: ComPacT NSX
• Model Designation: NSX100HB1
• Poles: 3
• Voltage Rating: 690VAC
• Interrupting Capacity: 75kA at 690VAC
• Trip Unit: MicroLogic 6.2EM
• Amperage Rating (Trip Unit): 80A
• Type: Molded Case Circuit Breaker (MCCB)

Applications & compatibility

This circuit breaker is suitable for use in power distribution systems, motor control centers, and heavy machinery applications where reliable overcurrent protection is critical. Its high interrupting rating makes it appropriate for installations with significant fault current potential, such as in manufacturing plants, data centers, or utility substations.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the C10V36M080 or contact our technical team for cross-reference assistance with compatible ComPacT NSX components.
