The Schneider Electric ComPacT NSX250F circuit breaker is engineered for robust electrical protection in demanding industrial environments. This 3-pole breaker, part of the ComPacT NSX series, features a 250A rating and a 36kA interrupting capacity at 415VAC, making it suitable for medium-voltage distribution and motor protection applications. Its integrated TMD trip unit provides adjustable thermal and magnetic protection settings.

Technical details

• Series: ComPacT NSX
• Model Designation: NSX250F
• Number of Poles: 3
• Rated Operational Voltage: 415VAC
• Interrupting Capacity: 36kA at 415VAC
• Trip Unit Type: TMD (Thermal Magnetic Drawout)
• Rated Current: 250A
• Enclosure Type: Drawout (indicated by 'F' in part number, typically for drawout versions)

Applications & compatibility

This circuit breaker is commonly deployed in power distribution panels, motor control centers, and electrical switchgear for protecting circuits and equipment in manufacturing plants, processing facilities, and infrastructure projects. It is designed to safeguard against overloads and short circuits in applications such as conveyor systems, pump controls, and HVAC units.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the C25F3TM250 or contact our technical team for cross-reference assistance with compatible ComPacT NSX components.
