The Schneider Electric TeSys GB2DB22 is a thermal magnetic circuit breaker designed for reliable circuit protection in industrial environments. This 2-pole breaker is part of the TeSys GB2 series, known for its robust construction and dependable performance in demanding applications. It offers a rated current of 20 Amperes and a breaking capacity of 1.5 kA at 415 Volts, making it suitable for safeguarding electrical circuits against overloads and short circuits.

Technical details

• Series: TeSys GB2
• Poles: 2
• Rated Current: 20 A
• Breaking Capacity (Icu): 1.5 kA @ 415 V AC
• Trip Type: Thermal Magnetic
• Mounting Type: DIN Rail Mount (typical for this series, verify with datasheet)
• Terminal Type: Screw Terminals (typical for this series, verify with datasheet)
• Operating Voltage: Designed for circuits up to 415 V AC

Applications & compatibility

This circuit breaker is commonly employed in control panels, motor starter assemblies, and distribution boards for various industrial machinery. It is suitable for protecting circuits in applications such as conveyor systems, pump controls, HVAC equipment, and general machine tool applications where reliable overcurrent protection is essential.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the GB2DB22 or contact our technical team for cross-reference assistance with compatible TeSys GB2 components.
