The Schneider Electric LA2DT4 is a control relay designed for industrial automation applications requiring timed switching operations. This component, part of the Schneider Electric control relay family, features a 1 Normally Closed (NC) and 1 Normally Open (NO) contact configuration, along with an adjustable ON-delay timer. Its functionality is crucial for sequencing operations in machinery and control panels where precise timing is a requirement.

Technical details

• Series: LA2DT
• Contact Configuration: 1 NC, 1 NO
• Function: ON-Delay Timer
• Adjustable Time Delay Range: 10 to 180 seconds
• Control Voltage: Verify against manufacturer datasheet for specific voltage requirements.
• Contact Rating: Verify against manufacturer datasheet for specific current and voltage ratings.
• Mounting Type: DIN rail mount (typical for this series, verify against datasheet)
• Operating Temperature: Verify against manufacturer datasheet for specific range.

Applications & compatibility

This control relay is commonly employed in applications such as motor control circuits, lighting control systems, and process automation sequences where a timed delay is needed before a circuit is energized or de-energized. It is compatible with various industrial control panels and systems that utilize Schneider Electric components or require similar timed relay functionality.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LA2DT4 or contact our technical team for cross-reference assistance with compatible Schneider Electric timing relay components.
