The Schneider Electric LADN10 is an auxiliary contact block designed for use with the TeSys D series of motor starters and contactors. This front-mounting unit features a single normally open (1NO) contact configuration, providing essential signaling capabilities for control circuits. It is engineered to integrate seamlessly with TeSys D contactors, enhancing their functionality in various industrial automation applications.

Technical details

• Series: TeSys D
• Contact Configuration: 1 Normally Open (1NO)
• Mounting Type: Front Mounting
• Terminal Type: Screw Terminals
• Contact Rating: Auxiliary contacts are typically rated for low voltage and current applications, suitable for signaling and control circuits. Specific voltage and current ratings should be verified against the TeSys D contactor datasheet for the complete system.
• Actuation: Mechanically linked to the main contactor pole.
• Environmental Rating: Designed for industrial environments; specific IP rating should be confirmed via manufacturer documentation.
• Dimensions: Compact design for minimal panel space when attached to a TeSys D contactor. Exact dimensions are available on the Schneider Electric product datasheet.

Applications & compatibility

This auxiliary contact block is commonly employed in motor control circuits to provide feedback on the status of a TeSys D contactor. Applications include signaling the energized or de-energized state of a motor starter to a PLC or HMI, enabling interlocking functions between different motor circuits, or triggering alarms based on contactor operation. It is compatible with the full range of Schneider Electric TeSys D contactors.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LADN10 or contact our technical team for cross-reference assistance with compatible TeSys D components.
