The Schneider Electric LC1D258B7 is a TeSys D series 4-pole contactor designed for AC-1 duty applications. This contactor is suitable for switching power circuits up to 440 Volts and 40 Amps. It features a 24 Volt AC coil for control power, making it a reliable component for motor control and power switching in various industrial automation systems.

Technical details

• Series: TeSys D
• Contactor Type: 4-Pole
• Contact Configuration: 2 Normally Open (NO) + 2 Normally Closed (NC)
• AC-1 Utilization Category: Suitable for AC-1 duty
• Maximum AC-1 Voltage: ≤ 440 V
• Maximum AC-1 Current Rating: 40 A
• Coil Voltage: 24 V AC
• Control Circuit Type: AC

Applications & compatibility

This Schneider Electric TeSys D contactor is commonly employed in motor control circuits for applications such as pumps, fans, compressors, and general power switching on assembly lines, material handling equipment, and HVAC systems. Its robust design and specific contact configuration ensure reliable operation in demanding industrial environments.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LC1D258B7 or contact our technical team for cross-reference assistance with compatible TeSys D components.
