Schneider Electric's TeSys LC1D series contactor is engineered for robust motor control applications. This 3-pole contactor, model LC1D4011F5, is designed for AC-3 duty, handling inductive loads up to 40 Amps at 440 Volts. Its integrated auxiliary contact configuration and coil voltage make it a reliable component for demanding industrial environments.

Technical details

• Series: TeSys LC1D
• Number of Poles: 3
• AC-3 Utilization Category: Rated for 40 A at 440 VAC
• Coil Voltage: 110 VAC
• Auxiliary Contacts: 1 Normally Open (NO) and 1 Normally Closed (NC)
• Mounting Type: DIN rail or screw mounting
• Terminal Type: Screw terminals
• Enclosure Rating: IP20 (finger-safe)

Applications & compatibility

This TeSys LC1D contactor is suitable for direct-on-line starting of three-phase motors in various industrial settings. It is commonly found in control panels for machinery such as pumps, fans, compressors, and conveyor systems. Its specifications ensure compatibility with standard motor control circuits requiring a 110 VAC coil.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LC1D4011F5 or contact our technical team for cross-reference assistance with compatible TeSys components.
