The Schneider Electric TeSys D contactor, model LC1DT80AJD, is a 4-pole device designed for AC-1 duty. This contactor is rated for circuits up to 440V and handles a continuous current of 80A. It features a standard 12V DC coil, making it suitable for integration into control systems requiring low-voltage DC activation.

Technical details

• Series: TeSys D
• Configuration: 4-pole (4 Normally Open - NO contacts)
• AC Rating: AC-1 duty
• Voltage Rating: Up to 440V AC
• Current Rating: 80A (AC-1 continuous)
• Coil Voltage: 12V DC
• Contact Type: 4 NO (Normally Open)
• Mounting: DIN rail or panel mount (verify mounting details against manufacturer datasheet)

Applications & compatibility

This TeSys D contactor is commonly employed in motor control applications and power switching circuits within industrial environments. It is suitable for use in control panels for machinery such as pumps, fans, compressors, and other equipment requiring reliable switching of inductive or resistive loads up to its rated capacity. Compatibility with 12V DC control circuits is a key feature for integration into existing automation architectures.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LC1DT80AJD or contact our technical team for cross-reference assistance with compatible TeSys D components.
