The Schneider Electric LC1E09008P7 is an EasyPact TVS series 4-pole contactor designed for AC-1 duty applications. This contactor features a configuration of 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts, providing versatile control options for motor starting and power switching circuits. It is rated for operation at 415V AC with a continuous current capacity of 20A.

Technical details

• Series: EasyPact TVS
• Poles: 4
• Auxiliary Contacts: 2 NO + 2 NC
• AC-1 Duty Rating: 20A at 415V AC
• Coil Voltage: 230V AC
• Terminal Type: Screw Terminals (verify against datasheet for specific wire gauge compatibility)
• Mounting: DIN rail or panel mount (verify against datasheet for specific dimensions and mounting hardware)
• Enclosure Rating: IP20 (finger-safe, verify against datasheet for specific environmental ratings)

Applications & compatibility

This contactor is suitable for general purpose AC-1 loads, commonly found in control panels for HVAC systems, lighting control, and basic motor control circuits where a direct-on-line start is employed. Its 4-pole configuration makes it ideal for switching single-phase loads or for applications requiring simultaneous switching of multiple circuits.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LC1E09008P7 or contact our technical team for cross-reference assistance with compatible EasyPact TVS components.
