The Schneider Electric TeSys K contactor, identified by the part number LP1K09105BD, is a 3-pole device designed for AC-3 duty applications up to 440V. This specific model integrates one normally open (NO) auxiliary contact and operates with a 24V DC coil, making it suitable for control circuits in various industrial automation systems. Its compact design and robust construction are characteristic of the TeSys K series, engineered for reliable switching operations in demanding environments.

Technical details

• Series: TeSys K
• Configuration: 3-Pole Contactor
• AC-3 Utilization Category: Rated for AC-3 duty up to 440V
• Current Rating: 9 Amperes (AC-3)
• Coil Voltage: 24V DC
• Auxiliary Contacts: 1 Normally Open (NO)
• Control Type: DC Coil
• Mounting: DIN rail or panel mount (verify mounting details against manufacturer datasheet)

Applications & compatibility

This TeSys K contactor is commonly employed in motor control applications, including direct-on-line starting, stopping, and reversing of three-phase motors. It finds application in control panels for machinery such as packaging equipment, conveyor systems, pumps, and ventilation units where precise and reliable motor switching is critical. Its compatibility extends to systems requiring a 24V DC control voltage for contactor activation.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LP1K09105BD or contact our technical team for cross-reference assistance with compatible TeSys K components.
