The Schneider Electric TeSys LRD1532 is a thermal overload relay designed for motor protection applications. This relay is part of the TeSys LRD series, a robust line of motor control components. It provides reliable protection against phase loss and unbalanced loads, crucial for maintaining the operational integrity of electric motors in demanding industrial environments.

Technical details

• Series: TeSys LRD
• Current Rating: 25...32 A adjustable
• Trip Class: Class 20
• Mounting Type: Direct mount to compatible TeSys contactors (verify compatibility with specific contactor model)
• Reset Type: Manual and automatic reset options available (verify specific unit configuration)
• Phase Loss Sensitivity: Yes, designed to detect phase loss
• Phase Unbalance Sensitivity: Yes, designed to detect phase unbalance
• Temperature Compensation: Built-in temperature compensation for ambient temperature variations

Applications & compatibility

This thermal overload relay is commonly integrated into motor control centers and individual motor starter assemblies for a wide range of industrial machinery. Applications include conveyor systems, pumps, fans, compressors, and machine tools where precise motor overload protection is essential to prevent damage and downtime.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LRD1532 or contact our technical team for cross-reference assistance with compatible TeSys components.
