The Schneider Electric LTM9BPS is a bypass unit designed for integration into motor control systems. This component facilitates the manual or automatic bypassing of a variable frequency drive (VFD) or soft starter, allowing for direct line power to the motor. The LTM series bypass units are engineered to provide operational continuity during maintenance, troubleshooting, or in the event of a drive failure, ensuring minimal downtime in critical industrial processes.

Technical details

• Series: LTM Bypass Unit
• Functionality: Motor bypass for VFD or soft starter
• Configuration: 3-pole bypass switch
• Control Input: Designed for integration with control logic systems
• Enclosure Type: Suitable for panel mounting
• Terminal Type: Screw terminals for secure connections
• Operational Mode: Supports manual and automatic bypass operations
• Component Type: Electrical bypass switch assembly

Applications & compatibility

This LTM9BPS bypass unit is commonly employed in applications requiring high motor uptime, such as on packaging lines, material handling systems, and pump or fan controls where continuous operation is paramount. It is designed to interface with Schneider Electric's Altivar variable speed drives and Tesys soft starters, providing a robust solution for maintaining motor operation during drive-related issues.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LTM9BPS or contact our technical team for cross-reference assistance with compatible Schneider Electric motor control components.
