The Schneider Electric Compact NSXm F circuit breaker, part number LV426772, is a 3-pole molded case circuit breaker designed for robust electrical protection in industrial environments. This unit features a 100 Ampere rating and a breaking capacity of 36 kA at 415 VAC, making it suitable for applications requiring significant fault current interruption. It integrates the Micrologic Vigi 4.1 trip unit for advanced protection functions.

Technical details

• Series: Compact NSXm F
• Poles: 3
• Rated Current: 100 A
• Breaking Capacity: 36 kA at 415 VAC
• Trip Unit: Micrologic Vigi 4.1
• Connection Type: Compression lugs and busbar connectors
• Voltage Rating: 415 VAC (confirmed for breaking capacity)

Applications & compatibility

This circuit breaker is commonly employed in motor control centers, distribution panels, and machinery requiring reliable overcurrent and short-circuit protection. Its specifications make it compatible with various industrial power distribution systems and compliant with international electrical standards.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV426772 or contact our technical team for cross-reference assistance with compatible Compact NSXm components.
