The Schneider Electric Compact NSXm H circuit breaker, identified by part number LV426792, is a 3-pole molded case circuit breaker designed for robust electrical protection in industrial environments. This unit features a 100 A current rating and a significant interrupting capacity of 70 kA at 415 VAC, making it suitable for applications requiring high fault current withstand. It integrates the Micrologic Vigi 4.1 trip unit, providing advanced protection and monitoring capabilities.

Technical details

• Series: Compact NSXm H
• Poles: 3
• Rated Current: 100 A
• Interrupting Capacity: 70 kA at 415 VAC
• Trip Unit: Micrologic Vigi 4.1
• Included Accessories: Compression lugs and busbar connectors
• Voltage Rating: Suitable for systems up to 415 VAC

Applications & compatibility

This circuit breaker is commonly deployed in power distribution systems for manufacturing facilities, data centers, and commercial buildings where reliable protection against overcurrents and short circuits is paramount. Its high interrupting rating makes it ideal for main incomer applications or branch circuit protection in areas with significant fault current potential, such as on assembly lines, in control panels, or within motor control centers.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV426792 or contact our technical team for cross-reference assistance with compatible Compact NSXm components.
