The Schneider Electric Compact NSX100H is a basic frame circuit breaker designed for robust electrical protection in demanding industrial environments. This 3-pole unit is engineered to handle significant fault currents, making it suitable for applications requiring high levels of safety and reliability. Its construction is based on the established Compact NSX series, known for its modularity and performance.

Technical details

• Series: Compact NSX
• Model Designation: NSX100H
• Number of Poles: 3
• Interrupting Capacity: 70 kA at 415 VAC 50/60 Hz
• Current Rating: 100 A
• Trip Unit: Not included; requires separate purchase for specific protection settings.
• Frame Size: Suitable for NSX100 applications.
• Voltage Compatibility: Designed for 415 VAC systems operating at 50/60 Hz.

Applications & compatibility

This circuit breaker frame is commonly integrated into power distribution systems for manufacturing plants, data centers, and commercial buildings. It serves as a foundational component for motor control centers, switchboards, and upstream protection for sensitive equipment. Compatibility is ensured with Schneider Electric's range of NSX trip units and accessories, allowing for tailored protection schemes.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV429004 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
