The Schneider Electric Compact NSX100N is a basic circuit breaker frame designed for robust electrical protection in industrial environments. This 3-pole frame is part of the widely recognized Compact NSX series, known for its reliability and modular design. It is engineered to accommodate a specific trip unit, allowing for customized protection settings based on application requirements.

Technical details

• Series: Compact NSX
• Frame Size: NSX100N
• Number of Poles: 3
• Rated Breaking Capacity: 50 kA at 415 VAC 50/60 Hz
• Rated Current: 100 A
• Trip Unit Compatibility: Designed to accept a separate trip unit (not included)
• Mounting Type: DIN rail or panel mount (verify mounting accessories separately)
• Terminal Type: Screw terminals (verify wire gauge compatibility with manufacturer datasheet)

Applications & compatibility

This circuit breaker frame is suitable for use in power distribution systems for a variety of industrial machinery and equipment. It is commonly found in applications such as motor control centers, main distribution panels, and branch circuit protection within manufacturing facilities, data centers, and commercial buildings.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV429006 or contact our technical team for cross-reference assistance with compatible Compact NSX trip units and accessories.
