The Schneider Electric TM16D trip unit is designed for use with Compact NSX 100 circuit breakers, providing essential thermal magnetic protection. This 4-pole unit is rated for 16 Amperes, ensuring reliable circuit interruption in demanding industrial environments. It is a key component for safeguarding electrical systems against overloads and short circuits.

Technical details

• Trip Unit Type: Thermal Magnetic
• Series: TM16D
• Compatible Circuit Breaker Series: Compact NSX 100
• Number of Poles: 4
• Current Rating: 16 A
• Protection Functionality: Overload and Short Circuit
• Form Factor: Trip Unit Module

Applications & compatibility

This TM16D trip unit is specifically engineered for integration into Schneider Electric Compact NSX 100 series circuit breakers. It is commonly deployed in motor control centers, power distribution panels, and machinery control systems across various industries, including manufacturing, food and beverage processing, and water treatment facilities.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV429057 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
