The Schneider Electric LV429124 is a magnetic trip unit designed for use with Compact NSX 100 circuit breakers. This unit provides essential overcurrent protection, featuring a 6.3 Ampere rating and a 3-pole (3d) configuration. It is engineered to ensure reliable operation in demanding industrial environments, safeguarding electrical systems from damage due to faults.

Technical details

• Trip Unit Type: Magnetic
• Series: Compact NSX 100
• Current Rating: 6.3 A
• Poles: 3d (3 poles)
• Functionality: Overcurrent protection
• Compatibility: Designed for Schneider Electric Compact NSX 100 circuit breakers. For specific voltage and interrupting capacity ratings, please consult the manufacturer's datasheet for the complete circuit breaker assembly.

Applications & compatibility

This trip unit is integral to the protection schemes of Schneider Electric Compact NSX 100 circuit breakers, commonly found in motor control centers, power distribution panels, and machine tool applications. Its precise current sensing ensures protection for equipment in manufacturing facilities, process plants, and building services.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV429124 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
