The Schneider Electric TM16G trip unit is designed for use with Compact NSX 100 circuit breakers, providing essential thermal magnetic protection. This 3-pole (3d) unit offers a precise 16 Ampere rating, making it suitable for safeguarding electrical circuits in demanding industrial environments. Its integration within the NSX platform ensures reliable performance for critical power distribution applications.

Technical details

• Trip Unit Type: Thermal Magnetic
• Series: Compact NSX
• Model Designation: TM16G
• Current Rating: 16 A
• Number of Poles: 3
• Pole Configuration: 3d (3 normally open, 3 normally closed contacts)
• Compatible Circuit Breaker Series: Compact NSX 100
• Protection Functionality: Overload and short-circuit protection

Applications & compatibility

This TM16G trip unit is specifically engineered for integration into Schneider Electric Compact NSX 100 series circuit breakers. It is commonly deployed in motor control centers, power distribution panels, and machinery control systems across industries such as manufacturing, food and beverage processing, and material handling. Its robust design ensures dependable operation in environments requiring precise circuit protection.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV429155 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
