The Schneider Electric ComPact NSX100F is a 3-pole circuit breaker designed for robust electrical protection in industrial environments. This unit features a 36kA interrupting capacity at 415VAC, ensuring safety and reliability in high-fault current situations. It is equipped with a TMD trip unit rated for 63A, providing precise overcurrent and short-circuit protection.

Technical details

• Series: ComPact NSX
• Model: NSX100F
• Number of Poles: 3
• Interrupting Capacity: 36kA at 415VAC
• Trip Unit Type: TMD
• Trip Unit Rating: 63A
• Configuration: 2d (refer to manufacturer datasheet for specific meaning of '2d' designation)

Applications & compatibility

This circuit breaker is suitable for use in distribution switchboards, motor control centers, and power distribution units across various industrial sectors. It is commonly found in applications requiring reliable protection for circuits feeding machinery such as pumps, fans, conveyors, and processing equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV429622 or contact our technical team for cross-reference assistance with compatible ComPact NSX components.
