The Schneider Electric LV433202 is a Compact NSX100R circuit breaker designed for robust electrical protection in industrial environments. This 3-pole unit features a 200 kA interrupting capacity at 415 VAC, ensuring safety and reliability in high-fault current situations. It is equipped with a TMD trip unit rated for 50 A, providing precise overcurrent and short-circuit protection.

Technical details

• Series: Compact NSX
• Model: NSX100R
• Number of Poles: 3
• Rated Current: 50 A (TMD trip unit)
• Interrupting Capacity: 200 kA at 415 VAC
• Trip Unit Type: TMD (Thermal Magnetic Differential)
• Voltage Rating: 415 VAC
• Configuration: 3d (refer to manufacturer datasheet for specific meaning of '3d')

Applications & compatibility

This circuit breaker is suitable for a wide range of industrial applications, including motor control centers, power distribution panels, and machine tool applications. Its high interrupting rating makes it ideal for systems where significant fault currents are anticipated, such as in manufacturing plants, data centers, and commercial buildings.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433202 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
