The Schneider Electric Compact NSX100HB1 is a 3-pole molded case circuit breaker designed for robust electrical protection in industrial environments. This unit is part of the NSX series, known for its reliability and performance in demanding applications. It offers a significant interrupting capacity, ensuring safety during fault conditions.

Technical details

• Series: Compact NSX
• Model: NSX100HB1
• Number of Poles: 3
• Interrupting Capacity: 85 kA at 500 VAC
• Trip Unit Type: TMD
• Current Rating: 40 A
• Configuration: 3d (refer to manufacturer datasheet for specific configuration details)
• Voltage Rating: Suitable for systems up to 500 VAC

Applications & compatibility

This circuit breaker is commonly employed in power distribution systems for machinery such as packaging lines, material handling equipment, and manufacturing automation. Its high interrupting rating makes it suitable for applications where short-circuit currents can be substantial, providing essential protection for downstream electrical components.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433210 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
