The Schneider Electric Compact NSX100HB1 is a high-breaking capacity circuit breaker designed for robust electrical protection in demanding industrial environments. This 3-pole unit is part of the Compact NSX series, known for its reliability and advanced protection features. It is engineered to safeguard electrical installations against overloads and short circuits, ensuring operational continuity and safety.

Technical details

• Series: Compact NSX
• Model: NSX100HB1
• Poles: 3d (3-pole)
• Breaking Capacity: 85 kA at 500 VAC
• Trip Unit Type: TMD (Thermal Magnetic Differential)
• Current Rating: 50 A
• Voltage Rating: Up to 500 VAC
• Enclosure Type: Compact

Applications & compatibility

This circuit breaker is suitable for a wide range of applications including motor control centers, power distribution panels, and industrial machinery protection. It is commonly found in manufacturing facilities, data centers, and infrastructure projects requiring reliable overcurrent protection up to 500 VAC.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433212 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
