The Schneider Electric Compact NSX100HB1 is a 4-pole molded case circuit breaker designed for robust electrical protection in industrial environments. This unit is part of the Compact NSX series, known for its reliability and advanced protection features. It offers a significant interrupting capacity, making it suitable for applications requiring high fault current handling.

Technical details

• Series: Compact NSX
• Model: NSX100HB1
• Number of Poles: 4
• Interrupting Capacity: 85 kA at 500 VAC
• Trip Unit Type: TMD (Thermal Magnetic Differential)
• Current Rating: 63 A
• Configuration: 4d (referring to the number of modules or poles, confirmed as 4 poles)
• Voltage Rating: Suitable for systems up to 500 VAC

Applications & compatibility

This circuit breaker is commonly employed in power distribution systems for manufacturing plants, data centers, and commercial buildings. It provides essential overcurrent and short-circuit protection for electrical panels, motor control centers, and critical equipment. Its high interrupting rating ensures safety in areas with potentially high fault currents, such as those found in heavy industrial machinery and large motor loads.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433215 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
