The Schneider Electric Compact NSX100HB1 is a molded case circuit breaker designed for robust electrical protection in industrial environments. This 3-pole unit is part of the Compact NSX series, known for its reliable performance and compact footprint. It offers a significant interrupting capacity, making it suitable for applications requiring protection against high fault currents.

Technical details

• Series: Compact NSX
• Model: NSX100HB1
• Poles: 3
• Interrupting Capacity: 85 kA at 500 VAC
• Trip Unit Type: TMD (Thermal Magnetic Drawout)
• Current Rating: 100 A
• Voltage Rating: Up to 500 VAC
• Configuration: 3d (3-pole, drawout)

Applications & compatibility

This circuit breaker is commonly employed in power distribution systems for commercial and industrial facilities, including motor control centers, switchboards, and panelboards. Its high interrupting rating makes it ideal for protecting downstream equipment in applications such as manufacturing plants, data centers, and infrastructure projects where fault current levels can be substantial.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric LV433218 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
