The Schneider Electric Compact NSX100R is a 3-pole circuit breaker designed for robust electrical protection in industrial settings. This unit features a 40 Amp rating and a high interrupting capacity of 200 kA at 415 VAC, making it suitable for demanding applications where fault current protection is critical. It incorporates the Micrologic 2.2 electronic trip unit for advanced overcurrent protection and selectivity.

Technical details

• Series: Compact NSX
• Model: NSX100R
• Number of Poles: 3
• Rated Current: 40 A
• Rated Voltage: 415 VAC
• Interrupting Capacity: 200 kA at 415 VAC
• Trip Unit: Micrologic 2.2
• Trip Unit Type: Electronic

Applications & compatibility

This circuit breaker is commonly specified for use in motor control centers, power distribution panels, and main incoming feeders within manufacturing facilities. Its high interrupting rating ensures safety and reliability in applications such as packaging machinery, material handling systems, and process control equipment where significant fault currents may occur.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433270 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
