The Schneider Electric Compact NSX100R circuit breaker is engineered for robust circuit protection in demanding industrial environments. This 3-pole breaker, part of the NSX series, features a high interrupting capacity of 200 kA at 415 VAC, ensuring safety and operational continuity. It integrates the Micrologic 2.2 M electronic trip unit for precise overcurrent and short-circuit detection.

Technical details

• Series: Compact NSX
• Model: NSX100R
• Number of Poles: 3
• Rated Current: 100 A
• Interrupting Capacity: 200 kA at 415 VAC
• Trip Unit: Micrologic 2.2 M (Electronic)
• Voltage Rating: 415 VAC
• Configuration: 3d (refer to manufacturer datasheet for specific configuration details)

Applications & compatibility

This circuit breaker is suitable for use in motor control centers, power distribution panels, and machinery requiring reliable protection against electrical faults. It is commonly found in applications such as conveyor systems, pump controls, and manufacturing automation lines where high fault currents are a consideration.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433276 or contact our technical team for cross-reference assistance with compatible NSX components.
