The Schneider Electric Compact NSX100R is a 4-pole circuit breaker designed for robust electrical protection in demanding industrial environments. This unit features a 200 kA interrupting capacity at 415 VAC, ensuring safety and reliability in high-fault current situations. It incorporates the Micrologic 5.2 E trip unit, providing advanced protection and control capabilities.

Technical details

• Series: Compact NSX
• Model: NSX100R
• Number of Poles: 4d (4 poles)
• Rated Current: 40 A
• Interrupting Capacity: 200 kA at 415 VAC
• Trip Unit: Micrologic 5.2 E
• Voltage Rating: 415 VAC
• Enclosure Type: Compact

Applications & compatibility

This circuit breaker is suitable for use in motor control centers, power distribution panels, and machine control systems across various industries. Its high interrupting rating makes it ideal for applications where significant fault currents are anticipated, such as in manufacturing plants, data centers, and infrastructure projects. The Micrologic 5.2 E trip unit offers adjustable settings for overload, short-circuit, and ground-fault protection, allowing for precise coordination with downstream equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433278 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
