The Schneider Electric Compact NSX100R is a 4-pole circuit breaker designed for robust electrical protection in demanding industrial environments. This unit features a Micrologic 5.2 E trip unit, providing advanced control and monitoring capabilities for critical power distribution systems. It is engineered to handle significant fault currents, ensuring operational safety and equipment longevity.

Technical details

• Series: Compact NSX
• Model: NSX100R
• Number of Poles: 4
• Trip Unit: Micrologic 5.2 E
• Rated Current: 100 A
• Interrupting Capacity: 200 kA at 415 VAC
• Configuration: 4d (refer to manufacturer datasheet for specific configuration details)
• Voltage Rating: 415 VAC

Applications & compatibility

This circuit breaker is commonly specified for use in motor control centers, power distribution panels, and main switchboards within manufacturing facilities. Its high interrupting rating makes it suitable for applications requiring protection against severe short-circuit conditions, such as those found in heavy machinery, process control systems, and large-scale automation projects.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433280 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
