The Schneider Electric Compact NSX100R circuit breaker is engineered for robust protection in demanding industrial environments. This 4-pole breaker, featuring a Micrologic 6.2 E trip unit, offers a significant interrupting capacity of 200 kA at 415 VAC, making it suitable for high-fault current applications. Its design is optimized for reliable operation within complex power distribution systems.

Technical details

• Series: Compact NSX
• Model: NSX100R
• Number of Poles: 4
• Trip Unit: Micrologic 6.2 E
• Rated Current: 40 A
• Interrupting Capacity: 200 kA at 415 VAC
• Voltage Rating: 415 VAC
• Form Factor: 4d (refer to manufacturer datasheet for detailed dimensions and mounting specifications)

Applications & compatibility

This circuit breaker is commonly deployed in motor control centers, power distribution panels, and machine control systems across various industries. It provides essential overcurrent and short-circuit protection for equipment such as pumps, conveyors, and manufacturing machinery, ensuring operational continuity and safety.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433282 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
