The Schneider Electric Compact NSX100R is a 4-pole circuit breaker designed for robust electrical protection in demanding industrial environments. This unit is part of the Compact NSX series, known for its reliability and advanced protection features. It offers a significant interrupting capacity, making it suitable for applications requiring high fault current withstandability.

Technical details

• Series: Compact NSX
• Model: NSX100R
• Number of Poles: 4
• Interrupting Capacity: 200 kA at 415 VAC
• Trip Unit: Micrologic 6.2 E
• Rated Current: 100 A
• Configuration: 4d (likely refers to the number of auxiliary contacts or specific internal configuration, buyer should verify with datasheet)

Applications & compatibility

This circuit breaker is commonly employed in power distribution systems for manufacturing plants, data centers, and commercial buildings. Its high interrupting rating makes it ideal for main incomer protection or critical feeder circuits where fault currents can be substantial. It is compatible with various Schneider Electric switchgear and distribution boards within the NSX product ecosystem.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433284 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
