The Schneider Electric Compact NSX100HB1 is a 3-pole circuit breaker designed for robust electrical protection in industrial environments. This unit features a Micrologic 2.2 trip unit with a 40 Amp rating, suitable for applications requiring precise overcurrent and short-circuit detection. Its high breaking capacity of 85 kA at 500 VAC ensures safety and reliability in demanding power distribution systems.

Technical details

• Series: Compact NSX
• Model Designation: NSX100HB1
• Trip Unit: Micrologic 2.2
• Rated Current: 40 A
• Number of Poles: 3
• Breaking Capacity: 85 kA at 500 VAC
• Voltage Rating: Up to 500 VAC
• Configuration: 3d (likely refers to the number of protected poles and auxiliary contacts, verify with datasheet)

Applications & compatibility

This circuit breaker is commonly deployed in motor control centers, power distribution panels, and machine tool applications where reliable circuit protection is paramount. It is designed to integrate seamlessly into systems requiring high fault current withstand capabilities, such as those found in manufacturing plants, data centers, and commercial buildings.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric LV433300 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
