The Schneider Electric Compact NSX100HB1 is a 3-pole circuit breaker designed for robust electrical protection in industrial environments. This unit features a Micrologic 2.2 trip unit and a 100 Ampere rating, making it suitable for applications requiring reliable overcurrent and short-circuit interruption. Its high breaking capacity ensures safety and operational continuity in demanding power distribution systems.

Technical details

• Series: Compact NSX
• Model: NSX100HB1
• Trip Unit: Micrologic 2.2
• Current Rating: 100 A
• Number of Poles: 3
• Breaking Capacity: 85 kA at 500 VAC
• Voltage Rating: Up to 500 VAC
• Configuration: 3d (3 normally open, 3 normally closed auxiliary contacts - *verify with datasheet*)

Applications & compatibility

This circuit breaker is commonly employed in motor control centers, power distribution panels, and machinery control systems across various industries. It is compatible with Schneider Electric's NSX accessory range for enhanced functionality and integration into existing electrical infrastructure. Applications include manufacturing plants, water treatment facilities, and building management systems.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433302 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
