The Schneider Electric Compact NSX100HB1 is a high-performance molded case circuit breaker designed for robust electrical protection in demanding industrial environments. This 3-pole unit, featuring a Micrologic 2.2 M electronic trip unit, offers advanced circuit interruption capabilities. It is commonly integrated into power distribution panels and motor control centers within manufacturing facilities.

Technical details

• Series: Compact NSX
• Model Designation: NSX100HB1
• Interrupting Capacity: 85 kA at 500 VAC
• Trip Unit: Micrologic 2.2 M
• Adjustable Trip Unit Current Rating: 25 A
• Number of Poles: 3
• Configuration: 3d (3 normally open, 3 normally closed auxiliary contacts)
• Voltage Rating: Suitable for circuits up to 500 VAC

Applications & compatibility

This circuit breaker is ideal for protecting electrical circuits in applications such as motor control, power distribution, and branch circuit protection across various industries. It is compatible with systems requiring reliable overcurrent and short-circuit protection, including those found in packaging machinery, material handling systems, and general industrial power distribution.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433304 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
