The Schneider Electric Compact NSX100HB1 is a 4-pole circuit breaker designed for robust electrical protection in demanding industrial environments. Part of the NSX series, this unit features a high interrupting capacity and is equipped with a Micrologic 5.2 E trip unit for advanced control and monitoring capabilities. It is commonly specified for use in power distribution panels and motor control centers within manufacturing facilities.

Technical details

• Series: Compact NSX
• Model: NSX100HB1
• Poles: 4
• Interrupting Capacity: 85 kA at 500 VAC
• Trip Unit: Micrologic 5.2 E
• Current Rating: 100 A
• Configuration: 4d (refer to manufacturer datasheet for specific meaning of '4d')
• Voltage Rating: Suitable for 500 VAC systems (verify specific operational voltage range against manufacturer datasheet)

Applications & compatibility

This circuit breaker is engineered for applications requiring reliable overcurrent and short-circuit protection, including motor circuits, distribution feeders, and general power distribution in sectors such as automotive manufacturing, food and beverage processing, and water treatment plants. It is designed to integrate seamlessly into Schneider Electric's NSX system architecture.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433310 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
