The Schneider Electric Compact NSX100HB1 is a high-performance molded case circuit breaker designed for robust electrical protection in industrial environments. Part of the esteemed Compact NSX series, this unit offers a significant interrupting capacity, making it suitable for applications requiring reliable fault current limitation. Its construction ensures durability and consistent operation under demanding conditions.

Technical details

• Series: Compact NSX
• Model Designation: NSX100HB1
• Rated Operational Voltage: 500 VAC
• Interrupting Capacity: 85 kA at 500 VAC
• Trip Unit: Micrologic 6.2 E-M
• Trip Unit Current Rating: 25 A
• Number of Poles: 3
• Configuration: 3d (3 normally open, 3 normally closed auxiliary contacts)

Applications & compatibility

This circuit breaker is commonly deployed in power distribution systems for manufacturing facilities, data centers, and commercial buildings. It is ideal for protecting motor circuits, feeder circuits, and main incoming power lines where a high interrupting rating is essential. Compatibility extends to various Schneider Electric switchgear and panelboard systems.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433315 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
